2.4m/8ft High XPD Dual-Polarized Microwave Parabolic Antenna
The XPD Antenna, short for Cross-Polarization Discrimination Antenna, is a specialized type of antenna known for its ability to reduce interference and improve signal clarity by minimizing cross-polarization interference. This type of antenna is designed to separate and distinguish between vertically and horizontally polarized signals, allowing for better discrimination and isolation of desired signals while rejecting unwanted interference.
- Our patent split-lobe microwave communication parabolic antenna for large diameter, which can save packaging and transportation costs greatly without any quality compromised；
- High performance ultra high XPD parabolic antennas – Excellent performance for a wide range of applications；
- Simple Assembly – Minimal required assembly simplifies installation on site and guarantees “factory-tested” quality；
Electrical performance:
Antenna Model | Antenna Size(m/ft) | Frequency (GHz) | Gain(dBi) | 3dB BW (degs) | XPD (dB) | VSWR | F/B radio (dB) | ISO | ||
| Low | Mid | Top | ||||||||
| CMP243DB | 2.4m/8ft | 3.6-4.2 | 36.1 | 37.3 | 38 | 2.4 | 33 | 1.15 | 62 | 38 |
| CMP244DB | 2.4m/8ft | 4.4-5.0 | 38.0 | 38.8 | 39.3 | 2.0 | 33 | 1.15 | 63 | 38 |
| CMP246WDB | 2.4m/8ft | 5.925-7.125 | 40.8 | 41.7 | 42.5 | 1.4 | 33 | 1.1 | 67 | 38 |
| CMP247WDB | 2.4m/8ft | 7.125-8.5 | 42.5 | 43.3 | 44.0 | 1.1 | 33 | 1.1 | 69 | 38 |
| CMP2410WDB | 2.4m/8ft | 10-11.7 | 45.5 | 46.1 | 46.8 | 0.8 | 33 | 1.1 | 71 | 38 |
| CMP2413WDB | 2.4m/8ft | 12.2-13.25 | 47.5 | 47.7 | 47.9 | 0.7 | 33 | 1.1 | 72 | 38 |
| CMP2415DB | 2.4m/8ft | 14.4-15.35 | 48.6 | 48.8 | 49.1 | 0.6 | 33 | 1.1 | 74 | 38 |
Mechanical performance:
| Diameter of Mounting Pole | φ114 mm |
| Fine Azimuth Adjustment | Coarse 360°Fine±5° |
| Fine Elevation Adjustment | Fine±5° |
| Wind Velocity Operational | 180km/h |
| Wind Velocity Survival | 200km/h |
| Ice-load | 25.4 mm |
| Operational Temperature | -55~+70℃ |
1.The low/mid/high gain has≤-0.5dBi tolerance is within the normal range;
2.F/Bradio:Denotes highest radiation relative to the main beam,at 180°±40°,across the band.Production antennas do not exceed rated values by more than 2 dB unless stated otherwise;
|
|
